Installation method:

To install aluminum: Knock the glue in the drilled hole and lock the aluminum strip to the wall with screws.

Fixing the glass: Clamp the glass to the hole in the bottom basin and fix it with screws.

Install the jacking pipe: find the corresponding position above the fixed glass to drill holes, install the (straight/slanted) fixing seat and connect the jacking pipe. Secure it to the top of the glass with an elbow sleeve.

Install the movable door: Install the hardware of the movable door, and install the hinge at the reserved hole of the fixed door. After installation, adjust the axis position of the hinge until the door feels the best when closing.

Do a good job of waterproofing: Install suction strips or water-retaining strips on the side or under the glass as required. Use silicone to seal the joints between aluminum and wall, glass and bottom basin.

Debugging and tightening: Check whether each part is comfortable and smooth to use, and adjust it in time if any problem is found. After adjustment, tighten the corresponding screws to make the entire shower room more stable.
